Chlorine, pH, ORP and Temperature Analyzers - Minimum required maintenance thanks to pre-mixed reagents
- Hinged Transparent Cover for Easy Maintenance
- Measurement Cell with LED Light Source
- pH regulation with both ON/OFF and proportional controls
- Separate alarms can be set for pH and chlorine controls
- Parameters can be sent through SMS
- Large graphical display with backlight
- User-friendly interface
- Can store up to 3500 data, that can be displayed or downloaded to a PC
Each PCA model is supplied complete with instructions. PCA 320-1 Free & Total Chlorine, pH and Temperature Analyzer, 115 VAC power supply. PCA 320-2 Free & Total Chlorine, pH and Temperature Analyzer, 230 Vac power supply. |
|
|
| Range | 0.00 to 5.00 mg/L | | Range | 0.00 to 14.00 pH | | Range | 5.0 to 75.0°C | | Resolution | 0.01 mg/L | | Resolution | 0.01 pH | | Resolution | 0.1 °C | | Accuracy (@20°C/68°F) | ±8% ±0.05 mg/L | | Accuracy (@20°C/68°F) | ± 0.05 pH | | Accuracy (@20°C/68°F) | ±0.5°C | | Minimum Detectable Level | 0.05 mg/L | | Input Impedance | 1012 Ohm | | Calibration | 1 point; 1 or 2 point | | Sampling Rate | adjustable from 3 to 90 minutes; adjustable from 3 | | Dosage | proportional with 4-20 mA output; ON/OFF with rela | | Delta | selectable from 0.1 to 5 mg/L; selectable from 0.1 | | Recorder Output | 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA or 0-20 mA | | Serial Communication | RS485 port, galvanically isolated | | Baud Rate | 1200, 2400, 4800, 9600 bps | | Data Logging | up to 3500 data series | | GSM Communication | 2 programmable cellular phone numbers, alarm & inf | | Alarm Relay | SPDT contact with 5A, 230 V resistive load | | Dosing Relay | SPDT contact with 5A, 230 V resistive load | | System Error | SPDT contact with 5A, 230 V resistive load | | Inlet Pressure | 0.07 to 4 bar with no external pressure regulator | | Sample Flow | 100 to 300 mL/min | | Sample Temperature | 5 to 40°C (41 to 104°F) | | Sample Inlet Connection | 12 mm (1/2') tubing diameter | | Drain Connection | 10 mm (3/8') bar fitting | | Power Supply | 115 Vac or 230 Vac; 50/60 Hz; 20 VA | | Enclosure | NEMA-4X standard, molded fiberglass polyester with | | Dimensions | 318 x 267 x 159 mm (12.5 x 10.5 x 6.25') | | Weight | 5 kg (11 lb.) without reagents |
|
|
|
Weight:
11.00 Pounds |
|
Dimensions:
0.00(L) x
0.00(W) x
0.00(H) Inches |
|
Weight Disclaimer: *Weight may vary based on configuration. |
|
|
|
