Conductivity Transmitters - Easy verification and monitoring of measured values
- 4-Ring potentiometric conductivity probe
- Automatically temperature compensated
HANNA instruments® 4-ring potentiometric conductivity probe is virtually immune to contamination by unclean solutions. This allows the transmitter to operate at peak performance at all times. Temperature effects are compensated for by the built-in temperature sensor on the probe and the transmitter's ATC circuitry with a temperature compensation (beta) of 2%/°C. Direct connection of the probe to the transmitter assures a positive electrical connection with no signal loss over long distances. Two versions are available, HI 8936 without an LCD, and the LCD version, HI 8936L. HI 8936L allows easy verification and monitoring of measured values, and is easier to calibrate and maintain. The HI 8936 series should be used in conjunction with the HI 7635 in-line probe or HI 7638 platinum probe (search Process Electrodes). The HI 8936 series requires external power to the 4-20 mA current loop.
All HI 8936 models are supplied complete with instructions. |
|
|
Range HI 8936A, HI 8936AL | 0.0 to 199.9 mS/cm | Range HI 8936B, HI 8936BL | 0.00 to 19.99 mS/cm | Range HI 8936C, HI 8936CL | 0 to 1999 µS/cm | Range HI 8936D, HI 8936DL | 0.0 to 199.9 µS/cm | Resolution HI 8936AL | 0.1 mS/cm | Resolution HI 8936BL | 0.01 mS/cm | Resolution HI 8936CL | 1 µS/cm | Resolution HI 8936DL | 0.1 µS/cm | Accuracy (@20°C/68°F) | ±2% of full scale | Calibration | 4 mA (zero) ±0.8 mA Slope: ±1.6 mA (90-110%) | Temp. Compensation | Fixed or automatic from 32 to 122°F (0 to 50°C) wi | Probe | HI 7635 or HI 7637 (not included) | Output | 4 to 20 mA not-isolated Max. 500 ohms | Protection | IP 65 | Battery Type / Life | without LCD: 12 to 30 VDC / with LCD 15 to 36 VDC | Environment | 32 to 122°F (0 to 50°C) 0-95% RH (non-condensing) | Dimensions | 6.5 x 4.3 x 3.5" (165L x 110W x 90Hmm) | Weight | 2.2 lbs (1Kg) |
|
|
Weight:
2.20 Pounds |
Dimensions:
0.00(L) x
0.00(W) x
0.00(H) Inches |
Weight Disclaimer: *Weight may vary based on configuration. |
|
|
|
